1000 Kva Pad Mounted Transformer

1000 KVA Pad Mounted Transformer Customized

EverNew transformer has customized an optimal 3-phase 1000 KVA pad mounted transformer for a US client, with a voltage rating of up to 34.5KV. This transformer utilizes a star connection (Y connection) and complies with the International Electrotechnical Commission (IEC) standard IEC60076, boasting excellent design and outstanding performance. Crafted meticulously by EverNew, this tailored 3 phase 1000 KVA pad-mounted transformer integrates cutting-edge technology with specific client requirements, ensuring a stable and reliable power supply. It serves as a robust support for the development and operation of urban power grids.

After a week of communication and collaboration, we finalized the solution and delivered the transformer two weeks later. This 1000KVA pad-mounted transformer complies with IEEE/ANSI, CSA, DOE, NEMA, and other standards, ensuring adherence to various regulatory requirements. In addition to UL certification, we also hold CSA, MF, CESI certificates, along with third-party SGS test reports. With over 30 years of design and production experience, we can customize transformers for each project, allowing adjustments to voltage, capacity, connection methods, and special designs to perfectly meet your needs.

Send Inquiry

1000 KVA 3 phase pad mounted transformer manufacturers

Main features of 1000 Kva Pad Mounted Transformer

The ZGS11 series combined transformer is a new type of distribution equipment. It features compact size and rational structure. Specifically designed for load-centered urban power grids, the combined transformer reduces energy consumption and improves power supply quality. Most importantly, this series of products has been widely applied in communities, public places, and industrial and mining enterprises across the country. Product Features:

The fully sealed insulation structure ensures personal safety.
It is applicable not only for ring networks but also for terminals.
Low loss, low noise, and superior performance.
Low temperature rise, high overload capacity.
The transformer adopts a special structure, highlighting its high quality.

Send Inquiry

1000 Kva Pad Mounted Transformer Applicable Standards

IEEE Std C57.12.00 – Standard for Standard General Requirements for Liquid-Immersed Distribution, Power, and Regulating Transformers.
IEEE Std C57.12.28 – Pad-Mounted Equipment – Enclosure Integrity.
IEEE Std C57.12.34 – Standard Requirements for Pad-Mounted, Compartmental-Type, Self-Cooled, Three-Phase Distribution Transformers
IEEE Std C57.12.90– Standard Test Code for Liquid-Immersed Distribution, Power, and Regulating Transformers and IEEE Guide for Short-Circuit Testing of Distribution and Power Transformers.
IEEE Std C57.12.91 – Guide for Loading Mineral-Oil-Immersed Transformers.

Send Inquiry

1000 KVA 3 phase pad mounted transformer manufacturers1

1000 KVA Pa Mount Transformer

75kva-2500kva oil transformer
Rated Cap acity(kVA)	High Voltage(v)	Low Voltage(v)	Connection Symbol	Standard	Short-circuit impedance(%)	Efficiency（%）
75	4160 7200 12000 12470 13200 13800 19920 24940 34500	110 220 230 400 480	Delta-Wye Dyn1 Ynyn0	IEEE /ANSI /DOE	4-7%	99.03
112.5						99.11
150						99.16
225						99.23
300						99.27
500						99.35
750						99.4
1000						99.43
1500						99.48
2000						99.51
2500						99.53

Send Inquiry

Installation of EverNew 1000 KVA Pad Mounted Transformer

For outdoor electrical installations, the 1000 KVA Pad Mounted Transformer serves as a reliable solution. Typically placed on a sturdy base, it is installed within a tank made of low carbon steel or stainless steel, featuring two doors and a secure locking mechanism.

Designed specifically to withstand outdoor conditions, the 1000 KVA Pad Mounted Transformer can operate in temperatures up to 30 degrees Celsius and at altitudes of up to 1000 meters. Its robust structure ensures durability and adaptability to various weather conditions.

The installation process involves carefully positioning the transformer on its base to ensure stability and secure attachment. The tank provides protection from environmental factors, while the doors allow for easy access when maintenance is required.

EverNew is a leading manufacturer of 1000 KVA Pad Mounted Transformer in China. We offer installation guidance services for 1000 KVA Pad Mounted Transformer. Contact us to have our technical service team assist you.

Send Inquiry

Installation of EverNew 1000 KVA Pad Mounted Transformer

Packaging of 1000 KVA Pad Mounted Transformer

Ensuring the safety of our 1000KVA Pad Mounted Transformer during transportation is paramount. EverNew employs sturdy standard wooden boxes for packaging, engineered to withstand transportation rigors and protect transformers from damage or misuse. Our commitment to quality extends from product design to delivery, prioritizing customer satisfaction and peace of mind.

At EverNew Transformer, we understand the importance of transportation security for sensitive electrical equipment. That’s why we ensure our packaging solutions offer maximum protection, allowing customers to receive transformers in pristine condition. Contact EverNew for reliable transformer supply and transportation security.

Send Inquiry

Schematic Diagram of 1000 KVA Pad Mounted Transformer

Explore the complex internal structure of a 1000 KVA Pad Mounted Transformer, carefully annotated to highlight its various components and structure. From the core and windings to the bushings and cooling systems, every aspect of a transformer’s design is critical to its efficient operation in a power distribution system.

EverNew Transformer moves from schematics to practical applications, providing comprehensive end-to-end services from product design to delivery. EverNew is committed to excellence and innovation, ensuring that each transformer is not only designed to perfection, but also rigorously tested to meet the highest quality standards. From initial concept to final installation, EverNew Transformer provides a seamless journey to deliver reliable, efficient power solutions for modern power infrastructure.
